如果您在使用數控焊接設備時遇到今天要講的問題，可以參考后進行處理，從而延長設備的使用壽命，讓其能正常使用。下面山東數控焊接設備廠家為您講解。

If you encounter the problems to be discussed today when using the NC welding equipment, you can refer to and deal with them later, so as to extend the service life of the equipment and enable it to be used normally. Next, Shandong CNC welding equipment manufacturer will explain to you.

設備電焊工超溫：

Equipment welder overtemperature:

(1)檢查電級座與心肌細胞之間接地電阻可否欠佳，并形成部分短路故障。

(1) Check whether the grounding resistance between the electrical base and the myocardial cell is poor, and form partial short circuit fault.

(2)檢查漏水壓力，出水量和供電溫度是否合適。檢查水道系統是否被塵土阻塞，電級臂，電級棒和電級頭因水冷卻欠佳而超溫。

(2) Check whether the leakage pressure, water output and power supply temperature are appropriate. Check whether the water channel system is blocked by dust, and the electric arm, electric rod and electric head are overheated due to poor water cooling.

(3)檢查銅軟聯和電級臂，電級桿和電級頭打戰面可否空氣氧化焦慮不安，形成打戰電阻器增加發燙焦慮不安。

(3) Check whether the fighting surface of copper soft link, electric grade arm, electric grade pole and electric grade head can oxidize anxiety in the air, and form a fighting resistor to increase the burning anxiety.

(4)檢查電級頭的截面是否由于損壞而過多增加，進而使焊機負載并產熱量。

(4) Check whether the section of the electric stage head is increased too much due to damage, which will load the welding machine and generate heat.

(5)檢查焊接薄厚、負荷持續率可否超標準，使焊機負載而發燙。

(5) Check whether the welding thickness and load continuity rate exceed the standard to make the welding machine hot under load.

設備踏下腳踏板焊機不工作，指示燈沒亮：

The welder does not work when the equipment steps down the foot pedal, and the indicator light does not light up:

(1)檢查開關電源動作電壓是否正常，自動控制系統是否正常。

(1) Check whether the switching power supply action voltage is normal and whether the automatic control system is normal.

(2)檢查踏板開關接觸、開關接觸和分開開關電源開關是否損壞。

(2) Check whether pedal switch contact, switch contact and disconnect switch power switch are damaged.

指示燈亮，鋼件卡緊不焊接：

The indicator light is on, and the steel parts are clamped and not welded:

(1)檢查腳踏板的日程是否及時，腳踏開關是否靈活。

(1) Check whether the schedule of the pedal is timely and whether the pedal switch is flexible.

(2)檢查數控焊接設備操縱桿的黃色螺釘是否能正確調整。

(2) Check whether the yellow screw of the control lever of the NC welding equipment can be adjusted correctly.

焊接過程中自設備不必要的濺水：

Unnecessary water splashing from equipment during welding:

(1)檢查電頭是否被空氣氧化。

(1) Check whether the electric head is oxidized by air.

(2)檢查焊接鋼的腐蝕和破碎情況。

(2) Check the corrosion and breakage of welded steel.

(3)檢查調整電源開關是否過高。

(3) Check whether the power switch is too high.

(4)檢查電壓是否太小，焊接過程是否準確。

(4) Check whether the voltage is too low and whether the welding process is accurate.

另外平時不要忘了對設備進行定期檢查，從而及時發現設備問題并處理。更多相關該設備的使用事項就來我們網站http://www.opedost.com進行咨詢吧！

In addition, don't forget to check the equipment regularly, so as to find and deal with equipment problems in time. More information about the use of this device can be found on our website http://www.opedost.com Consult!
