數控焊接設備的類型很多，但基本相同。它們包括四個主要組件：控制設備，控制設備，電源設備和過程支持設備。使用前，少要確保數控焊接設備的這些支撐部件完好無損且正常。另外，您應該注意什么？

There are many types of numerical control welding equipment, but they are basically the same. They include four main components: control equipment, control equipment, power supply equipment and process support equipment. Before use, at least ensure that these supporting parts of the NC welding equipment are intact and normal. In addition, what should you pay attention to?

數控焊接設備是與焊接輥架，焊接定位器和其他產品一起使用的一種設備。使用它，可以將焊接設備發送并固定在要焊接的位置，或者以選定的焊接速度沿指定路徑移動。為正確進行焊接工作提供良好的基礎。

Numerical control welding equipment is a kind of equipment used with welding roller frame, welding positioner and other products. With it, you can send and fix the welding equipment at the position to be welded, or move along the specified path at the selected welding speed. Provide a good foundation for correct welding.

使用數控焊接設備時，必須可靠地對其進行定位和夾緊，這可以防止和減少焊接變形并將工件放置在理想的焊接位置。這對于確保焊接良好地形成并提高焊接速度是有用的。的。

When using numerical control welding equipment, it must be reliably positioned and clamped, which can prevent and reduce welding deformation and place the workpiece in the ideal welding position. This is useful for ensuring that the welding is well formed and improving the welding speed. of

對于數控焊接設備，應盡可能使用通用的標準化焊接支持設備，以幫助充分發揮機械手的效率；當然，所選擇的數控焊接設備必然具有更好的制造工藝和更好的高機械效果，否則將無法正常使用。

For numerical control welding equipment, general standardized welding support equipment should be used as far as possible to help give full play to the efficiency of the manipulator; Of course, the selected CNC welding equipment must have better manufacturing process and better high mechanical effect, otherwise it will not be able to be used normally.

當使用數控焊接設備時，對支撐設備的選擇，特別是設備的剛性以及設備的形狀和尺寸精度有很高的要求。焊接開始時，導熱，導電性，磁絕緣和絕緣對焊接設備有特定要求。

When using numerical control welding equipment, there are high requirements for the selection of supporting equipment, especially the rigidity of the equipment and the shape and dimensional accuracy of the equipment. At the beginning of welding, heat conduction, conductivity, magnetic insulation and insulation have specific requirements for welding equipment.

如果焊接變位機必須在厚板之間焊接較大的焊縫，并且在焊接之前兩個金屬板之間幾乎沒有空間，則在整個焊接過程中無法移動零件，等等一旦整個焊縫完全冷卻并收縮，所有的收縮應力將被焊縫直接吸收，因此，如果焊縫受到很大的應力，則收縮應力可能會導致焊縫之間出現嚴重裂紋焊接。

If the welding positioner must weld a large weld between thick plates, and there is almost no space between the two metal plates before welding, the parts cannot be moved during the whole welding process, etc. once the whole weld is completely cooled and contracted, all the shrinkage stress will be directly absorbed by the weld seam. Therefore, if the weld seam is under great stress, the shrinkage stress may lead to serious crack welding between the welds.

山東數控焊接設備廠家認為特別是兩個金屬板之間的一次焊接容易出現裂紋，但是如果兩個金屬板之間的間隙比較小，當焊接收縮時，我們可以稍微移動下金屬板以降低完整性間隙的減小，這也將導致整個焊縫的橫向應力適當減小。如果您要焊接一塊較大的，相對較厚的鋼板，則兩個金屬板之間的整個接縫的間隙應為0.8毫米，但如果情況允許，則接縫的間隙必須為1.6毫米。

Shandong numerical control welding equipment manufacturer believes that cracks are easy to appear especially in the one-time welding between two metal plates, but if the gap between the two metal plates is relatively small, when the welding shrinks, we can slightly move the lower metal plate to reduce the reduction of the integrity gap, which will also lead to the appropriate reduction of the transverse stress of the whole weld. If you want to weld a large, relatively thick steel plate, the gap of the entire joint between the two metal plates should be 0.8 mm, but if circumstances permit, the gap of the joint must be 1.6 mm.
